Product description
PC PeripheralsHeadsets & AudioExternal sound cards from xDuoo
TA-66 AMP is an OTL tube headphone amplifier from xDuoo that combines several high-quality components to deliver a refined audio experience. It uses a 6N2 tube for the amplification stage and a 6N5P tube for the buffer stage, creating a smooth and charming sound character. The device is intended for music listening and gaming, allowing for enhanced audio quality for various headphones and active speakers. The build quality includes a solid aluminum casing with a sandblasted surface, providing both visual aesthetics and structural durability. A step-by-step potentiometer addresses volume imbalance and helps maintain homogeneous sound levels. Furthermore, point-to-point soldering and copper wiring in the tube circuit minimize interference and maximize sound reproduction. Equipped with professional metal-polyester film capacitors, professional audio performance is ensured. Summary- OTL tube headphone amplifier
- 200mW output power at 300Ω load
- Designed for audio enthusiasts and gamers
- Equipped with 6N2 and 6N5P tubes for sound processing
- Sandblasted aluminum casing for both aesthetics and durability
Product Specifications:
Power Source
AC 110V (100–120V) / 220V (220–240V)
Output Power
200mW (at 300Ω load)
Frequency Range
10Hz–30KHz (±1dB)
Audio Performance
Gain (Amplification): +18dB
THD+N (Total harmonic distortion + noise): 0.08% (at 1KHz and 300Ω load)
S/N (Signal-to-Noise Ratio): 107dB
Compatibility
Suitable Earphone Impedance: 60Ω–600Ω
Additional
Size (Length * Width * Height): 29.0 * 15.3 * 18.4 cm
Weight: 5.0 Kg
Article number:
Our article number: 36495
Manuf. article number: 8413222399456
Brand
xDuoo (Shenzhen xDuoo Technology Co., Ltd.) is a Chinese manufacturer of audio equipment focused on high-quality DAC units, headphone amplifiers, tube amplifiers, and digital music players. The company targets both portable and desktop audiophiles, combining classic analog sound characteristics with modern HiFi technology.
By combining technical expertise, flexible product development, and competitive pricing, xDuoo has established itself as a strong player in the global HiFi market, offering products for both beginners and experienced users.
Specifications
Properties
| Color | Grey |
Warranty
| Manufacturer's warranty | 1 year warranty |
